Pressure Powered Condensate Pump

Pressure Powered Condensate Pump Specification

Features
No external power required, Rugged design, High efficiency, Easy maintenance

Max Suction
Up to 4.5 meters

Control System
Mechanical Float or Level Control

Caliber
25 mm to 80 mm

Discharge Pressure
Upto 16 bar

Head Size
Up to 12 meters

Inlet/Outlet
DN25 to DN80, Flanged Connection

Theory
Pressure Powered Mechanical Pump

Noise Level
Below 70 dB (A)

Mounting Type
Floor Mounted / Skid Mounted

Working Temperature
Up to 200C

Flow Rate
Up to 20 m/h

Voltage
Manual Operation (No electrical power required)

Material
Carbon Steel / Stainless Steel / Cast Iron

Structure
Horizontal, Pressure Vessel with Internal Mechanism

Power

Standard
ASME / DIN / ISO

Fuel Type
Non-electric/Pressure Powered

Pressure
Design upto 16 bar

Usage
Condensate Recovery for Steam Systems

Application
Industrial Steam Plants, HVAC, Chemical, Pharmaceutical, Food & Beverage

Suction Type
Single Suction

Seals Type
High-Temperature Resistant Seals

Priming
Self-priming

Pump Type
Pressure Operated Condensate Pump

Capacity
From 500 kg/h to 15,000 kg/h

Internal Mechanism
Stainless Steel Float & Linkage

Discharge Outlet Height
Customizable per Site Requirements

Backflow Prevention
Integrated Non-return Valve

Design Life
20+ Years under Normal Operation

Inspection Opening
Available for Maintenance Access

Body Finish
Corrosion Resistant Epoxy Coating

Compatible Fluids
Condensate, Water, Light Hydrocarbons

Ambient Operating Temperature
Up to 70°C

Pressure Powered Condensate Pump Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
1 Week

About Pressure Powered Condensate Pump

Discover the celebrated IEPL Pressure Powered Condensate Pump, a best-seller renowned for its praiseworthy efficiency and rugged design. Highlighted in industrial steam plants and HVAC, this spectacular pump features corrosion-resistant epoxy coating, a stainless steel float mechanism, and high-temperature seals, ensuring 20+ years of reliable service. Experience promotion-worthy productivity with its customizable discharge outlet and integrated non-return valve. Operating without electricity, powered by steam or air, this self-priming pump offers high capacity, quiet operation, and easy maintenance-an exporter and manufacturer in India trusted for excellence.

Advantage & Application of Pressure Powered Condensate Pump

This pressure powered condensate pump offers the advantage of non-electric, highly efficient condensate recovery with minimal maintenance. It performs spectacularly in areas such as chemical, pharmaceutical, food & beverage, and industrial steam systems, making it a celebrated solution for HVAC and process industries. Designed for high durability and corrosion resistance, these pumps are ideal for environments demanding reliability and custom performance, such as boiler houses, utility rooms, and production facilities.

Packaging, Payment, and Delivery Information

All goods are securely packaged for safe transport to your location. The asking price varies by model and capacity, with multiple payment terms accepted for customer convenience. Goods are typically delivered within a standard time frame to ensure prompt installation and commissioning. Choose IEPL for seamless purchasing and dependable delivery; satisfaction is guaranteed from enquiry to the moment your pump is efficiently delivered and installed at your site.

Specification

Model Name/Number	IEPL 1 TO 12 TPH
Brand	IEPL
Pump Type	ELECROMECHANICAL
Usage/Application	Industrial
Power Source	AIR OR STEAM
Material	MILD STEEL
Phase	Single Phase
Automation Grade	Semi-Automatic
Color	TATA BLUE
Body Material	MILD STEEL
Warranty	1 YEAR
I Deal In	New Only

FAQ's of Pressure Powered Condensate Pump:

Q: How does the pressure powered condensate pump operate without electrical power?

A: The pump works using steam, air, or other pressurized gas as its power source, relying on a mechanical float or level control to initiate the pumping process, eliminating the need for electrical energy.

Q: What are the application areas for IEPL condensate pumps?

A: IEPL pumps are ideal for industrial steam systems, HVAC, chemical processing, pharmaceutical production, and food & beverage facilities, where condensate recovery is crucial for efficient operation.

Q: When should maintenance be performed on the condensate pump?

A: Routine inspection and maintenance can be easily performed through the available inspection opening. Maintenance frequency depends on operating conditions, but periodic checks are recommended to sustain longevity.

Q: Where can these pressure powered pumps be installed?

A: These pumps are suitable for installation in floor-mounted or skid-mounted configurations within boiler rooms, plant utilities, or manufacturing facilities requiring condensate recovery.

Q: What benefits does the integrated non-return valve offer?

A: The integrated non-return valve prevents backflow, enhancing the pump's reliability and efficiency while reducing the risk of operational interruptions and maintenance needs.

Q: How is the discharge outlet height customized for site requirements?

A: Discharge outlet height is tailored for each site during installation, ensuring optimal flow and compatibility with your facility's layout and process needs.

Q: What is the process for ordering and payment?

A: Customers can inquire about pricing, select preferred payment terms, and expect secure packaging and prompt delivery upon order confirmation, facilitated by IEPL's experienced export and supply chain team.
