Boiler Condensate Pump

Boiler Condensate Pump Specification

Working Temperature
-10C to 120C

Theory
Centrifugal Pump

Discharge Pressure
Upto 6 bar

Features
Robust construction, Low maintenance, Energy efficient

Speed
2900 rpm

Head Size
15-55 m

Voltage
220V / 380V

Noise Level
Low (70 dB)

Flow Rate
2-10 m/h

Frequency
50 Hz / 60 Hz

Control System
Automatic / Manual

Inlet/Outlet
25 mm / 25 mm

Caliber
25 mm

Max Suction
8 m

Mounting Type
Baseplate Mounted

Material
Cast Iron / Stainless Steel

Structure
Horizontal

Power
0.75-4 kW

Standard
ISI / ISO

Fuel Type
Electric

Pressure
Max. 6 bar

Usage
Boiler System Condensate Transfer

Application
Industrial Boilers, Steam Systems

Suction Type
Single Stage

Seals Type
Mechanical Seal

Priming
Self-priming

Pump Type
Centrifugal Condensate Pump

Capacity
2-10 m/h

Connection Type
Threaded or Flanged

Impeller Type
Enclosed

Service Life
Long-lasting

Corrosion Resistance
Yes

Weight
Approx. 35 kg

Cooling Method
Air cooled

Max Liquid Temperature
120°C

Vibration
Very Low

Operational Mode
Continuous Duty

Protection Class
IP55

Motor Type
Asynchronous motor

Max Ambient Temperature
40°C

Boiler Condensate Pump Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
1 Week

About Boiler Condensate Pump

Introducing our Steam Condensate Pumps, an essential component for efficient steam system operation. Designed for reliability and longevity, these pumps seamlessly recover and transport condensate back to the boiler, preventing energy waste. Crafted with precision engineering, they excel in diverse industrial environments, ensuring consistent performance. The user-friendly design facilitates easy integration into existing systems, enhancing overall steam system efficiency. By reclaiming and recycling condensate, these pumps contribute to significant energy savings and reduced environmental impact. Elevate your steam system's performance with our Steam Condensate Pumps a reliable solution that underscores efficiency, sustainability, and cost-effectiveness in industrial operations.

Specification

Max Flow Rate	1 TPH to 12 TPH
Model Name/Number	IEPL CONDENSATE ERECOVERY PUMP
Brand	Innovative Enerpro Pvt Ltd.
Capacity	1 TPH TO 12 TPH
Color	Blue
Material	S.S, M.S
Country of Origin	Made in India

Efficient Boiler Condensate Transfer

Specially built for industrial boilers and steam systems, this pump delivers dependable condensate removal. The centrifugal design ensures consistent flow rates between 2 and 10 m3/h, while the strong cast iron or stainless steel body withstands high pressures and temperatures. With a maximum head of 55 m and up to 6 bar pressure, it is ideal for demanding applications.

Durable and Safe Operation

Integrity is achieved through an enclosed impeller and mechanical seals, both contributing to a leak-free and long-lasting operation. The IP55 protection class secures the pump against dust and water ingress, and the air-cooled asynchronous motor, coupled with self-priming capability, enables seamless, low-maintenance use even in continuous duty cycles.

Flexible Installation and Control Options

Whether you require threaded or flanged connections, installation is straightforward and adaptable. The pump comes baseplate-mounted for stability, and users can choose between manual or automatic control systems for integration with modern boiler room setups. Energy-efficient design assures quiet operation, with noise levels below 70 dB, making it suitable for diverse environments.

FAQ's of Boiler Condensate Pump:

Q: How does the boiler condensate pump handle high-temperature liquids?

A: The pump is engineered to operate with liquids up to 120C, utilizing corrosion-resistant materials and mechanical seals to ensure safety and reliability under elevated temperatures typical in boiler applications.

Q: What benefits does the IP55 protection class provide for this pump?

A: An IP55 protection rating safeguards the pump against dust and low-pressure water jets, making it suitable for industrial environments where exposure to moisture and particles is common, thereby enhancing longevity and operational reliability.

Q: Where can this boiler condensate pump be installed?

A: This pump is ideal for installation in industrial boiler rooms and steam systems, thanks to its baseplate-mounted structure, flexible connection options (threaded or flanged), and capacity to operate under continuous duty in challenging conditions.

Q: What control systems are available for operating the pump?

A: Users can operate the pump manually or integrate it into automatic control systems, facilitating smooth and efficient boiler condensate transfer processes as per specific application requirements.

Q: How is maintenance simplified on this pump?

A: With its enclosed impeller, air-cooled motor, mechanical seal, and corrosion-resistant construction, the pump requires minimal maintenance, reducing downtime and ensuring consistent performance over a long service life.

Q: What is the process for priming and starting the pump?

A: The pump features a self-priming design which automatically removes air from the system, enabling straightforward startup and reliable performance, even after shutdowns or installation in new systems.
